Primed White FD30 Fire Rated Softwood Door Lining with Loose Stop 2100 x 120 x 32mm

Key features

• FD30 fire-rated softwood construction for compliant fire-safety doorways
• Pre-primed white finish reduces on-site preparation and provides moisture protection
• Routered for intumescent strip installation to maintain fire integrity under heat
• Loose stop allows flexible fitting to suit various door thicknesses
• 2100mm height suits standard internal doorway openings
• 120 x 32mm (5" x 1") profile provides solid frame support
• Ready-to-install component reduces assembly time on site
• Softwood material is easy to cut, drill, and finish with standard tools

Specifications

Fire rating

FD30

Material

Softwood

Finish

Primed white

Height

2100mm

Width

120mm

Depth

32mm

Imperial size

5" x 1"

Stop type

Loose (removable)

Routing

Pre-routered for intumescent strips

Moisture content

Suitable for internal use

Certification

Compliant with FD30 fire-safety requirements

Common applications

• Internal doorway frames in residential properties requiring fire safety
• Commercial office and retail fire-compartment doorways
• Stairwell and corridor fire-rated door installations
• Apartment and flat entrance doors meeting building regulations
• Hospital, care home, and institutional fire-safety doorways
• Listed building and heritage property internal doors (where fire safety is required)
• New-build residential fire-safety door frames
• Retrofit fire-safety upgrades to existing internal doorways
• Landlord compliance installations for rental properties
• Building regulation-compliant door frame replacement

Search keywords

FD30 fire rated door lining · fire rated softwood door lining · primed white door lining · door lining 2100mm · door lining 120 x 32mm · door lining 5 x 1 · door lining 5" x 1" · fire safety door frame · intumescent strip door lining · loose stop door lining · FD30 door frame softwood · internal fire rated door lining · primed door lining white · door lining with loose stop · routered door lining intumescent · fire compartment door lining · building regulations door lining · FD30 compliant door lining · softwood door lining primed · door lining 120mm width · door lining 32mm depth · fire rated door frame 2100 · pre-primed door lining · door lining for fire doors · internal doorway fire lining · 5" x 1" · 5x1 · 5 x 1 · 120 x 32mm

Description

This FD30 fire-rated door lining is manufactured from softwood and supplied primed white, offering a durable frame component for internal doorways that must meet fire safety standards. The 2100 x 120 x 32mm profile (5" x 1") is routered along its length to accommodate intumescent strips, which expand under heat to seal gaps and maintain fire integrity. The loose stop allows flexibility during installation and can be fitted to suit your specific door thickness and swing direction.

The primed finish protects the timber during transit and storage, and provides a neutral base for painting or staining on site. This lining is suitable for use with FD30-rated doors and frames in residential and commercial applications where fire compartmentalisation is required. Installation is straightforward with standard carpentry techniques, and the loose stop design simplifies adjustment for different door leaf thicknesses.
